CHAPTER 2
Installing the ERX System 2-2
Figure 2-1 Packaged ERX-1400 series
To unpack the ERX-1400 series:
1
Cut the two straps that secure the carton to the skid. See Figure 2-1 .
2
Open the carton from the top.
3
Remove the box of accessories that sits on top of the router.
4
Unlock the four plastic clips that hold the box to the skid by
squeezing them in their center and pulling out. See
Figure 2-1 .
5
Lift the carton off the router. See Figure 2-2 .
Shipping
carton
Shipping
skid
Clips
Shipping
straps
