CHAPTER 2
Installing the ERX System 2-8
To install the system in the rack:
1
On the rack, identify and mark the holes that you want to use for
mounting the system.
2 One person should stand on the left side of the system, and another
should stand on the right side.
3
Grasp the lower back of the unit with one hand and the lower front
of the unit (see
Figure 2-4 ) with the other hand.
4
Bend your knees and carefully lift the unit into position in the rack.
5
With the help of the third person, align the holes in the system’s
flanges with the holes in the rack, and hold the system in position.
6
Starting at the bottom, the third person should screw the flange on
each side of the system into the four holes on each side of the rack.
7 Connect the necessary cables (see Chapter 4, Cabling the ERX
System , for instructions on installing the cables).
Figure 2-6 illustrates a distribution rack with one ERX-1410 system and
two ERX-700 systems installed.
