300X Series Technical Manual 7610-002-64-22
Issued: 07-26-2006 Revised: N/A
SECTION 1: SPECIFICATION INFORMATION
ELECTRICAL REQUIREMENTS
300X
RINSE
TYPICAL
HEATER
TOTAL ELECTRICAL
VOLTS
PH
HZ
RATINGS AMPS
CIRCUIT
208 1 50
12 KW@240V 71
90 AMP
208 1 50
14 KW@240V 78
100 AMP
230 1 50
12 KW@240V 78
100 AMP
230 1 50
14 KW@240V 86
110 AMP
208 3 50
12 KW@240V 45
60 AMP
208 3 50
14 KW@240V 49
70 AMP
230 3 50
12 KW@240V 48
60 AMP
230 3 50
14 KW@240V 53
70 AMP
380 3 50
12 KW@380V 29
40 AMP
*380 3 50
14 KW@208V 34
45 AMP
415 3 50
12 KW@415V 26
35 AMP
415 3 50
14 KW@415V 29
40 AMP
440 3 50
12 KW@460V 21
30 AMP
440 3 50
14 KW@460V 25
35 AMP
208 1 60
12 KW@240V 69
90 AMP
208 1 60
14 KW@240V 76
100 AMP
230 1 60
12 KW@240V 76
100 AMP
230 1 60
14 KW@240V 84
110 AMP
208 3 60
12 KW@240V 43
60 AMP
208 3 60
14 KW@240V 47
60 AMP
230 3 60
12 KW@240V 46
60 AMP
230 3 60
14 KW@240V 51
70 AMP
460 3 60
12 KW@480V 22
30 AMP
460 3 60
14 KW@480V 24
30 AMP
300XN
RINSE
TYPICAL
HEATER
TOTAL ELECTRICAL
VOLTS
PH
HZ
RATINGS AMPS
CIRCUIT
208 1 50
N/A
28
35 AMP
230 1 50
N/A
30
40 AMP
208 3 50
N/A
20
25 AMP
230 3 50
N/A
21
30 AMP
380 3 50
N/A
10
15 AMP
415 3 50
N/A
10
15 AMP
440 3 50
N/A
8
15 AMP
208 1 60
N/A
26
35 AMP
230 1 60
N/A
28
35 AMP
208 3 60
N/A
18
25 AMP
230 3 60
N/A
28
35 AMP
460 3 60
N/A
8
15 AMP
300XLT
RINSE
TYPICAL
HEATER
TOTAL ELECTRICAL
VOLTS
PH
HZ
RATINGS AMPS
CIRCUIT
208 1 50
N/A
28
35 AMP
230 1 50
N/A
30
40 AMP
208 3 50
N/A
20
25 AMP
230 3 50
N/A
21
30 AMP
380 3 50
N/A
10
15 AMP
415 3 50
N/A
10
15 AMP
440 3 50
N/A
8
15 AMP
208 1 60
N/A
26
35 AMP
230 1 60
N/A
28
35 AMP
208 3 60
N/A
18
25 AMP
230 3 60
N/A
28
35 AMP
460 3 60
N/A
8
15 AMP
300XS
RINSE
TYPICAL
HEATER
TOTAL ELECTRICAL
VOLTS
PH
HZ
RATINGS AMPS
CIRCUIT
208 1 50
N/A
7
15 AMP
230 1 50
N/A
7
15 AMP
208 3 50
N/A
7
15 AMP
230 3 50
N/A
7
15 AMP
380 3 50
N/A
7
15 AMP
208 1 60
N/A
6
15 AMP
230 1 60
N/A
6
15 AMP
208 3 60
N/A
6
15 AMP
230 3 60
N/A
6
15 AMP
460 3 60
N/A
2
15 AMP
* This unit is wired in a wye configuration for the heaters.
3
NOTE: Typical Electrical Circuit is based upon (1) 125% of the full amperage load of the machine and (2) typical fixed-trip
circuit breaker sizes as listed in the NEC 2002 Edition. Local codes may require more stringent protection than what is dis-
played here. Always verify with your electrical service contractor that your circuit protection is adequate and meets all
applicable national and local codes. These numbers are provided in this manual simply for reference and may change with-
out notice at any given time.
