300X Series Technical Manual 7610-002-64-22
Issued: 07-26-2006 Revised: N/A
SECTION 6: PARTS SECTION
STEAM TUB ASSEMBLY (CONTINUED)
ITEM QTY DESCRIPTION Mfg. No.
1 1 Tub Weldment 05700-002-79-58
2 1 Rack Assembly 05700-002-01-00
1 Rack Guide 05700-001-28-19
3 2 Bulk Head Plug 04730-609-05-00
4 1 See page entitled “Wash Motors” N/A
5 1 Gasket 05700-111-35-03
6 1 O-ring 05330-400-05-00
7 4 Bolt, Hex 3/8”-16 x 1 1/4" Long 05305-276-10-00
8 1 Lower Wash Manifold Weldment 05700-031-46-00
9 1 Suction Strain Weldment 05700-001-22-23
10 1 Suction Strain Bracket 05700-001-22-24
11 8 Locknut, 1/4"-20 with Nylon Insert 05310-374-02-00
12 1 Strainer Weldment 05700-021-50-07
13 1 Wash Overflow Weldment 05700-001-25-69
14 1 Overflow Support Bracket 05700-001-27-55
15 1 O-Ring 05330-400-05-00
16 2 Clamp, Hose 1 5/16” to 2 1/4” 04730-719-01-37
17 1 Discharge Hose 05700-011-88-24
18 1 Nipple 05700-021-34-84
19 1 Pump Support Bracket Assembly 05700-002-00-46
20 1 Clamp, Hose 5 5/8" to 6" 04730-011-34-90
21 1 Connector, 1/2” 90 B 05975-111-01-00
22 4 Nut, 3/8"-16 S/S Hex 05310-276-01-00
23 4 Lockwasher 3/8” 05311-276-01-00
24 1 Fitting, 1/4" Imperial Brass 05310-924-02-05
25 1 Switch, Dual Float 06680-002-68-63
26 1 Clamp, 1/8" Nylon 05975-601-10-15
27 1 Cover, Wash Heater 05700-031-47-57
28 1 Decal, Warning-Disconnect Power 09905-100-75-93
29 2 Locknut, 10-24 with Nylon Insert 05310-373-01-00
30 3 Locknut, 6-32 with Nylon Insert 05310-373-03-00
31 1 Kit, Thermostat, Regulating 06401-003-18-56
32 1 Steam Coil Assembly 05700-002-08-62
42
