300X Series Technical Manual 7610-002-64-22
Issued: 07-26-2006 Revised: N/A
SECTION 6: PARTS SECTION
CONTROL BOX ASSEMBLY (CONTINUED)
34
ITEM QTY DESCRIPTION Mfg. No.
1 1 Control Box Weldment 05700-002-57-70
2 1 Fuse Holder 05920-401-03-14
3 1 Transformer 05950-400-01-35
4 1 Relay 05945-301-07-40
5 2 Relay, 24V, 10A 05945-002-63-02
6 1 Timer 05945-307-07-93
7 1 Inner Panel 05700-002-57-35
8 1 Switch, Magnetic Reed 05930-002-36-80
9 1 Decal, L1, L2, L3 09905-101-12-66
10 1 Ground Lug 05940-200-76-00
11 1 Decal, Ground 09905-011-86-86
12 1 Terminal Block 05940-011-48-27
13 1 Contactor (not used on 300XN/XLT/XS) 05945-109-01-09
14 1 Relay 05945-109-02-09
15 1 Din Rail, 9 05700-001-26-97
16 1 Relay (not used on 300XN/XLT/XS) 05945-109-03-09
17 1 Digital Display 06685-400-04-00
18 1 Light, Yellow 05945-504-02-90
19 1 Decal, Control Box 09905-002-57-40
20 1 Switch, Manual 05930-002-63-06
21 1 Light, Blue 05945-504-05-90
22 1 Switch, Cycle 05930-002-63-05
23 1 Light, White 05945-504-03-90
24 1 Switch, Power 05930-002-63-04
25 4 Leg, Control Box 05700-002-33-05
* 4 Screw, 1/4”-20 x 2 3/4” Hex Head Cap 05305-274-13-00
* 4 Washer, 1/4”-20 ID S/S 05311-174-01-00
* 4 Locknut, 1/4”-20 S/S Hex with Nylon Insert 05310-374-01-00
26 1 Decal, Warning-Disconnect Power 09905-100-75-93
27 1 Cover, Top Mount Control Box 05700-002-23-03
* 4 Screw, 10-32 x 3/8” Phillips Truss Head 05305-173-12-00
28 1 Decal, Copper Conductors 09905-011-47-35
29 1 Decal, Line Voltage 09905-107-02-12
30 1 Overload (460 Volt Units Only) 05945-304-02-09
Associated Hardware:
Locknut, 10-24 S/S Hex with Nylon Insert
05310-373-01-00
Screw, 10 x 18-8 x 1” S/S Phillips Pan Head 05305-002-63-46
Screw, 10 x 18-8 x 3/8” S/S Phillips Pan Head 05305-002-63-47
Screw, 6 x 18-8 x 3/8” S/S Phillips Pan Head 05305-002-63-49
Screw, 6-32 x 3/8” Phillips Truss Head 05305-171-07-00
