300X Series Technical Manual 7610-002-64-22
Issued: 07-26-2006 Revised: N/A
SECTION 6: PARTS SECTION
THERMOSTATS / WASH HEATERS / RINSE HEATERS
44
To order the thermostats:
Thermostat, High Limit
05930-011-49-43
Kit, Thermostat, Wash Tank
06401-140-00-32
The 300X models covered in this manual come supplied with various heaters, depending on the characteristics of the machine. To
ensure that you order the correct heater for the model you are servicing, please refer to the following table:
40°F Rise
70°F Rise
Model
Volts
Hz
Phase
Wash Heater
Rinse Heater (12 KW)
Rinse Heater (14 KW)
300X
208
50
1
04540-121-47-39
04540-121-47-40
04540-121-63-38
300X
208
50
3
04540-121-47-39
04540-121-47-40
04540-121-63-38
300X
208
60
1
04540-121-47-39
04540-121-47-40
04540-121-63-38
300X
208
60
3
04540-121-47-39
04540-121-47-40
04540-121-63-38
300X
230
50
1
04540-121-47-39
04540-121-47-40
04540-121-63-38
300X
230
50
3
04540-121-47-39
04540-121-47-40
04540-121-63-38
300X
230
60
1
04540-121-47-39
04540-121-47-40
04540-121-63-38
300X
230
60
3
04540-121-47-39
04540-121-47-40
04540-121-63-38
300X
380
50
3
04540-002-44-31
04540-002-44-32
04540-121-63-38
300X
415
50
3
04540-002-43-09
04540-002-43-10
04540-002-77-24
300X
440
50
3
04540-121-65-99
04540-100-01-15
04540-121-63-39
300X
460
60
3
04540-121-65-99
04540-100-01-15
04540-121-63-39
300XN/XLT
208
50
1
04540-121-47-39
300XN/XLT
208
50
3
04540-121-47-39
300XN/XLT
208
60
1
04540-121-47-39
300XN/XLT
208
60
3
04540-121-47-39
300XN/XLT
230
50
1
04540-121-47-39
300XN/XLT
230
50
3
04540-121-47-39
300XN/XLT
230
60
1
04540-121-47-39
300XN/XLT
230
60
3
04540-121-47-39
300XN/XLT
380
50
3
04540-002-44-31
300XN/XLT
415
50
3
04540-002-43-09
300XN/XLT
440
50
3
04540-121-65-99
300XN/XLT
460
60
3
04540-121-65-99
NOTE: THE 300XS is heated via steam coils and therefore has no electrical heaters.
