Jackson Enodis 300X - Manual (Page 45)

300X Series Technical Manual 7610-002-64-22
Issued: 07-26-2006 Revised: N/A
SECTION 6: PARTS SECTION
TUB ASSEMBLY (CONTINUED)
40
ITEM QTY DESCRIPTION Mfg. No.
1 1 Tub Weldment 05700-002-59-18
2 1 Rack Assembly 05700-002-01-00
1 Rack Guide 05700-001-28-19
3 2 Bulk Head Plug 04730-609-05-00
4 1 Switch, Dual Float 06680-002-68-63
5 1 Gasket 05700-111-35-03
6 1 O-ring 05330-400-05-00
7 4 Bolt, Hex 3/8”-16 x 1 1/4" Long 05305-276-10-00
8 1 Lower Wash Manifold Weldment 05700-031-46-00
9 1 Suction Strain Weldment 05700-001-22-23
10 1 Suction Strain Bracket 05700-001-22-24
11 8 Locknut, 1/4"-20 with Nylon Insert 05310-374-02-00
12 1 Strainer Weldment 05700-021-50-07
13 1 Wash Overflow Weldment 05700-001-25-69
14 1 Overflow Support Bracket 05700-001-27-55
15 1 O-Ring 05330-400-05-00
16 2 Clamp, Hose 1 5/16” to 2 1/4” 04730-719-01-37
17 1 Discharge Hose 05700-011-88-24
18 1 Nipple 05700-021-34-84
19 1 Pump Support Bracket Assembly 05700-002-00-46
20 1 Clamp, Hose 5 5/8" to 6" 04730-011-34-90
21 1 Connector, 1/2” 90 B 05975-111-01-00
22 4 Nut, 3/8"-16 S/S Hex 05310-276-01-00
23 4 Lockwasher 3/8” 05311-276-01-00
24 1 Fitting, Olflex 05975-205-43-00
25 1 Union, 1/4” 05700-001-16-52
26 1 Clamp, 1/8" Nylon 05975-601-10-15
27 1 Locknut, 6-32 with Nylon Insert 05310-373-03-00
28 4 Lockwasher, 5/16", S/S, Split 05311-275-01-00
29 4 Nut, Hex, 5/16"-18, S/S 05310-275-01-00
30 4 Locknut, 10-24 with Nylon Insert 05310-373-01-00
31 1 Cover, Wash Heater 05700-031-47-57
32 1 Decal, Warning-Disconnect Power 09905-100-75-93
33 1 Kit, Thermostat, Regulating 06401-003-18-28
34 1 Thermostat, High Limit 05930-121-71-36
35 1 Fitting, 1/4" Imperial Brass 05310-924-02-05
36 1 Wash Heater Gasket 05330-011-47-79
