Front Riggings Reference Chart
NOTE: Calf pads with attaching hardware not included on legrest.
NOTE: Pivot/ Slide tube attaching hardware not included.
NOTE: Pivot/ Slide tube and footplates do not include heel loops. See footrest and legrest accessories.
NOTE: Pivot/ Slide tube and footplates are interchangeable with the support assemblies listed above
them.
Support Assemblies - PW93ST and 70ST TAPER
Side
PW93ST
70ST TAPER
8881026996
8881070784
Right
See Note(s) A
See Note(s) A
8881026997
8881070785
Left
See Note(s) A
See Note(s) A
A - Specify frame color when ordering.
NOTE:
Pivot/ Slide Tube and Footplates
Side
C
15-17" W
C
18-19" W
C
20-22" W
1057879
1057869
1057859
Right
1057880
1057870
1057860
Left
1057881
1057871
1057861
Right
2" Longer
1057882
1057872
1057862
Left
2" Longer
