Invacare ESS-PTO - Manual (Page 85)

Front Riggings Reference Chart
NOTE: Calf pads with attaching hardware not included on legrest.
NOTE: Pivot/ Slide tube attaching hardware not included.
NOTE: Pivot/ Slide tube and footplates do not include heel loops. See footrest and legrest accessories.
NOTE: Pivot/ Slide tube and footplates are interchangeable with the support assemblies listed above
them.
Pivot/ Slide Tube and Footplates
Side
AT5543
16-22" W
1650
14-15" W
1650
16-22" W
1450
16-22" W
1350
17-22" W
AT5543
14-15" W
1091777 1091775 1035456 1023924 1023907 1023905 Right
1091778 1091776 1035457 1023925 1023908 1023906 Left
C = 1651 Composite footplate with 9-7/8" curved pivot/ slide tube.
AT5543 = Adjustable angle footplates with 9-7/8" straight pivot/ slide tube.
1650 = Aluminum footplate with "L" style pivot/ slide tube.
1450 = Deluxe aluminum footplate with "L" style pivot/ style tube.
1350 = Extra large footplate with "L" style pivot/ slide tube.
AT5043 = Flip up footplates without pivot/ slide tubes.
Support Assemblies - P93M
Side Part Number
8881037836
Right
See Note(s) A
8881037837
Left
See Note(s) A
A - Specify frame color when ordering. NOTE:
84
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-038
