Seat pan and mounting hardware – Invacare ESS-PTO User Manual
Page 53
Seat Pan and Mounting Hardware
For ASBA Seats (12-15" Wide) & (16-22" Wide Before 7/5/05)
Item
Number
Part Number
Description
Note
Quantity Per
Package Assembly
See Chart
#1 Seat Pan 12"-18"
1
1
1
See Chart
#1 Seat Pan 19"-22"
1
1
1
1070459
Kit, Seat Pan Mounting Hardware
1
1
6
A
Screw, Hex Head (1/4-20 x 1-5/8")
1
2
2
Screw, Hex Head (1/4-20 x 1-1/2")
1
4
3
Spacer (1/4 x 3/8 x 3/16")
1
4
4
Locknut (1/4-20)
1
6
5
A - Includes items 2-5
NOTE:
#1 Seat Pan - 12" D to 18" D
Seat Width
12-15" Deep
16" Deep
17" Deep
18" Deep
N/A
N/A
1070513
1066009
12" Wide
N/A
N/A
1070514
1066010
13" Wide
1066033
1066022
1066011
1066022
14" Wide
1066034
1066023
1066012
1066023
15" Wide
1066035
1066024
1066013
1066024
16" Wide
1066036
1066025
1066014
N/A
17" Wide
1066037
1066026
1066015
N/A
18" Wide
1066038
1066027
1066016
N/A
19" Wide
1066039
1066028
1066017
N/A
20" Wide
1066040
1066029
1066018
N/A
21" Wide
1066041
1066030
1066019
N/A
22" Wide
NOTE: 12-15" seat depths are achieved by using CJ back cane mounting hardware.
52
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-038
