Front Riggings Reference Chart
NOTE: Calf pads with attaching hardware not included on legrest.
NOTE: Pivot/ Slide tube attaching hardware not included.
NOTE: Pivot/ Slide tube and footplates do not include heel loops. See footrest and legrest accessories.
NOTE: Pivot/ Slide tube and footplates are interchangeable with the support assemblies listed above
them.
Support Assemblies - P904A
Side
Part Number
8881058646
Right
See Note(s) A
8881058647
Left
See Note(s) A
A - Specify frame color when ordering.
NOTE:
Pivot/Slide Tube and Footplates
Side
AT5543
16-22" W
1650
14-15" W
1650
16-22" W
1450
16-22" W
1350
17-22" W
AT5543
14-15" W
1062756
1060444
1058830
1028723
1058604
1058612
Right
1062757
1060445
1058831
1028724
1058605
1058613
Left
1062760
1062758
1086541
N/A
1086529
N/A
Right
2" Longer
1062761
1062759
1086551
N/A
1086531
N/A
Left
2" Longer
N/A
N/A
1086542
N/A
1086530
N/A
Right
4" Longer
N/A
N/A
1086552
N/A
1086532
N/A
Left
4" Longer
Support Assemblies - PAS4A/PAL4A
Side
Part Number
1058482
Right
1058483
Left
83
