Invacare ESS-PTO - Manual (Page 45)

Metal Curved Back Assembly
NOTE: Curved Back mounts only to back canes without a 10 degree bend.
NOTE: As of 8/15/08 the Curved Back material changed from ABS Plastic to Metal as inventory runs out.
You must ask the customer if they have an ABS Plastic or the Metal Curved Back model when replacing
components. All service replacement Back Assemblies with Hardware shipped will be metal. New
Headrest Mounting Hardware is required when replacing an ABS Curved Back with a Metal Curved Back.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
See Chart #1 Back Pan w/ Vinyl Edge Trim 16"-18" Wide 1 1 1
See Chart #1 Back Pan w/ Vinyl Edge Trim 19"-22" Wide 1 1 1
See Chart #2 Back Cushion Assembly 16"-18" Wide 1 1 2
See Chart #2 Back Cushion Assembly 19"-22" Wide 1 1 2
See Chart #3 Back Assembly with Hardware 16"-18" Wide 1 1 3
See Chart #3 Back Assembly with Hardware 19"-22" Wide 1 1 3
1125723 Kit, Hook Fastener w/ Adhesive Back 1 1 4 A
1125724 Trim, Edge, Cut-To-Length, Vinyl Black (96" L) 1 1 5
A - Hook Fastener Adhesive Kit is used to attach the Back Cover to the Back Pan and must be ordered when a new Back Pan
or Back Assembly is requested.
NOTE:
#1 Back Pan w/ Vinyl Edge Trim - 16"-18" Wide
Overall
Back Height
Material
Back Height
16" Wide 17" Wide 18" Wide
1157848 1157837 1157826 11" 16"
1157849 1157838 1157827 12" 17"
1157850 1157839 1157828 13" 18"
1157851 1157840 1157829 14" 19"
1157852 1157841 1157830 15" 20"
1157853 1157842 1157831 16" 21"
1157854 1157843 1157832 17" 22"
1157855 1157844 1157833 18" 23"
1157856 1157845 1157834 19" 24"
NOTE: Hook Fastener Adhesive Kit must be ordered when a Back Pan or Back Assembly is requested. This will allow the Loop Fastener
Adhesive on the Back Cover to attach properly.
