Invacare ESS-PTO - Manual (Page 86)

Front Riggings Reference Chart
NOTE: Calf pads with attaching hardware not included on legrest.
NOTE: Pivot/ Slide tube attaching hardware not included.
NOTE: Pivot/ Slide tube and footplates do not include heel loops. See footrest and legrest accessories.
NOTE: Pivot/ Slide tube and footplates are interchangeable with the support assemblies listed above
them.
Pivot/ Slide Tube and Footplates
Side
1650
14-15" W
1650
16-22" W
1450
16-22" W
1350
17-22" W
1031924
1028892-NLA
1057969 1058573 Right
See Note(s) A
1031925
1028893-NLA
1057970 1058574 Left
See Note(s) A
1086519 N/A N/A N/A
Right
2" Longer
1086523 N/A N/A N/A
Left
2" Longer
1086520 N/A N/A N/A
Right
4" Longer
1086524 N/A N/A N/A
Left
4" Longer
A - No longer available as a service part individually. NOTE:
Support Assemblies - 70MFX and 90 SWING
Side 70 MFX 90 SWING
8881062596 8881047481
Right
See Note(s) A See Note(s) A
8881062597 8881047480
Left
See Note(s) A See Note(s) A
A - Specify frame color when ordering. NOTE:
Footrest Tube and Footplates
For AT5043 and AT5543
Side
AT5043
12-16" W
AT5543
12-13" W
AT5543
14-15" W
AT5543
17-22" W
1062570 1060438 1060436 1029434 Right
1062571 1060439 1060437 1029435 Left
85
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-038
