ABS Curved Back Assembly

NOTE: ABS curved back mounts only to Storm Series back canes without a 10 degree bend.

NOTE: As of 8/15/08 the Curved Back material changed from ABS Plastic to Metal as inventory runs out.

You must ask the customer if they have an ABS Plastic or the Metal Curved Back model when replacing

components. All service replacement Back Assemblies with Hardware shipped will be metal. New

Headrest Mounting Hardware is required when replacing an ABS Curved Back with a Metal Curved Back.

Item

Number

Part Number

Description

Note

Quantity Per

Package Assembly

See Chart

#1 Back Pan 16"-18"

See Chart

#1 Back Pan 19"-22"

See Chart

#2 Back Cushion Assembly 16"-18"

See Chart

#2 Back Cushion Assembly 19"-22"

See Chart

#3 Back Assembly with Hardware 16"-18"

See Chart

#3 Back Assembly with Hardware 19"-22"

1125723

Kit, Hook Fastener w/ Adhesive Back

A - Not Shown. Hook Fastener Adhesive Kit is used to attach the Back Cover to the Back Pan and must be ordered when a

new Back Pan or Back Assembly is requested.

NOTE:

#1 Back Pan - 16" Wide to 18" Wide

Overall

Back Height

Material

Back Height

16" Wide

17" Wide

18" Wide

1086023-NLA

1086022-NLA

1086021-NLA

12"

16"

See Note(s) A

1086030-NLA

1086029-NLA

1086028-NLA

13"

17"

See Note(s) A

1086037-NLA

1086036-NLA

1086035-NLA

14"

18"

See Note(s) A

1086044-NLA

1086043-NLA

1086042-NLA

15"

19"

See Note(s) A

1086051-NLA

1086050-NLA

1086049-NLA

16"

20"

See Note(s) A

1086058-NLA

1086057-NLA

1086056-NLA

17"

21"

See Note(s) A

1086065-NLA

1086064-NLA

1086063-NLA

18"

22"

See Note(s) A

1086072-NLA

1086071-NLA

1086070-NLA

19"

23"

See Note(s) A

1086079-NLA

1086078-NLA

1086077-NLA

20"

24"

See Note(s) A

A - Part Number is No Longer Available. See Category page titled "Backs - Metal Curved Assembly" and use the item "Back
Assembly w/ Hardware" to find replacement part numbers. Match the wheelchair width by the material back height when ordering.

NOTE:

NOTE: Hook Fastener Adhesive Kit must be ordered when a Back Pan or Back Assembly is requested. This will allow the Loop Fastener
Adhesive on the Back Cover to attach properly.
