Invacare ESS-PTO - Manual (Page 77)

Arms, Adjustable Height
(16"-22" Wide) x (16"-22" Deep) Seat Frames
Item
Number Part Number Description Note
Quantity Per
Package Assembly
8881015932 Pad, Arm, Vinyl, Full Length - Right (14" L x 2" W) 1 1 1 A
8881015933 Pad, Arm, Vinyl, Full Length - Left (14" L x 2" W) 1 1 1 A
8881011811 Pad, Arm, Vinyl, Desk Length (9" L x 2" W) 1 1 1 A
1071253 Arm Tube Assembly w/ Plug Buttons, Full Length,
Black - Right/Left 1 1 2
1070859 Arm Tube Assembly w/ Plug Buttons, Desk Length,
Black - Right/Left 1 1 2
1027095 Plug Button, Black (7/8") 1 2 3
1055949 Package, Screw, Phillips Pan Head (#10-32 x
1-1/8") (Pair) 2 1 4
1064130 Guard, Clothing 1 1 5
47471X074 Spring, Arm Lock 1 1 6
1028594 Pin, Arm Lock, Black 1 1 7
1032244 Grip, Foam Hand (9" L) 1 1 8
1090768 Kit, Lock Handle w/Rivets (Pair) 2 1 9
1028645 Rivet 1 6 10
1065936 Plug, Pivot 1 2 11
1067734 Plug Button, Black (5/8") 1 2 12
1068416 Arm Base Assembly, Black - Right (16-19" D) 1 1 13 B
1068417 Arm Base Assembly, Black - Left (16-19" D) 1 1 13 B
1068418 Arm Base Assembly, Black - Right (20" and Deeper) 1 1 13 C
1068419 Arm Base Assembly, Black - Left (20" and Deeper) 1 1 13 C
1035065 Cover, Clothing Guard w/ Pocket, FXDESK &
ADJFULL/ADJDESK 1 1 14
A - Specify U67 black upholstery color when ordering.
B - 16"-19" Deep
C - 20"-22" Deep. The ADJASBA seat frame for 19-22" depths must use the 16-19" deep arms only. NOTE:
76
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-038
