MKIV Quad Pulse and GB Controller Mounting Hardware
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1070504 Fastener, Hook with Adhesive Back (1" W x 1" L) 1 2 1
1104258 Screw, Hex Head w/ Patch (5/16-18 x 1") 1 2 2
1092659 Kit, Controller Mounting Bracket with Fastener
Strips, Black 1 1 3
1040223 Screw (#8-32 x 1/2") 1 3 4
1104260-NLA NLA - Wire, Grounding Jumper Strap E.S.D. 1 1 5
1027263 Washer, Lock Tooth (3/16 x 3/8 x 1/32") 1 1 6
1079245 Clamp, Cable 1 2 7
1028755 Screw, Phillips Pan Head (#10-32 x 5/8") 1 2 8
1025735 Locknut (#10-32) 1 2 9
1087790-NLA NLA - Bracket, Controller Mounting, Black 1 1 10
40163X002 Screw, Phillips Round Head (#10-32 x 1/2") 1 3 11
1092650 Bracket with Hardware, Controller Mounting 1 1 12 A
1092651 Bracket with Hardware, Controller Mounting 1 1 13 B
1107312-NLA NLA - Bracket with Hardware, Controller Mounting 1 1 14 C
1107311-NLA NLA - Bracket with Hardware, Controller Mounting 1 1 15 D
A - Includes items 1-6
B - Includes items 1-8
C - Includes items 4-6, 9 and 10
D - Includes items 5-11 NOTE:
144
