Curve Contoura Back w/o Mounting Hardware - After
5/14/09
#1 Mesh Curved Contoura Back Kit (CTBMSH)
Dimensions
Material
Back
Height
16" Wide 18" Wide 20" Wide 22" Wide
1164241 1164239 1164237 1164235
20" High 25" High
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
1164242 1164240 1164238 1164236
23" High 28" High
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
A - Includes items 2-9 NOTE:
Overall Back Height includes the spacing gap dimension from the bottom of the Back Assembly to the Seat Pan
64
