Back Cane and Attaching Hardware
For ASBA Seats (12"-15" Wide) & (16"-22" Wide Before 7/5/05)
Item
Number
Part Number
Description
Note
Quantity Per
Package Assembly
See Chart
#1 Back Cane and Mounting Hardware
1
2
1
1135506
Package, Foam Hand Grip (9" L)
10
1
2
1134426
Package, Plug Button, Black (3/4")
10
1
3
1070499
Kit, Back Cane Attaching Hardware, For CJ Bracket
12-13" Deep Seat
2
1
4
A
Insert, Non-Threaded Back Cane
(For Back Heights 20" and Lower)
1
2
5
Washer (1/4 x 23/32 x 1/16")
1
8
7
Locknut (1/4-20)
1
8
8
Spacer, Coved (1/4 x 11/16 x 1/2")
1
8
9
Bracket, Back Mounting, Black - Right
1
1
10
Bracket, Back Mounting, Black - Left
1
1
10
Screw, Hex Head (1/4-20 x 1-5/8")
1
4
11
1070500
Kit, Back Cane Attaching Hardware, For CJ Bracket
14-15" Deep Seat
2
1
4
A
Insert, Non-Threaded Back Cane
(For Back Heights 20" and Lower)
1
2
5
Washer (1/4 x 23/32 x 1/16")
1
8
7
Locknut (1/4-20)
1
8
8
Spacer, Coved (1/4 x 11/16 x 1/2")
1
8
9
Bracket, Back Mounting, Black - Right
1
1
10
Bracket, Back Mounting, Black - Left
1
1
10
Screw, Hex Head (1/4-20 x 1-5/8")
1
4
11
1106554
Kit, Back Cane Attaching Hardware
2
1
4
B,C,E
Insert, Non-Threaded Back Cane
(For Back Heights 20" and Lower)
1
2
5
Screw, Hex Head (1/4-20 x 1-5/8")
1
4
6
Washer (1/4 x 23/32 x 1/16")
1
4
7
Locknut (1/4-20)
1
4
8
Spacer, Coved (1/4 x 11/16 x 1/2")
1
4
9
1106555
Kit, Back Cane Attaching Hardware
2
1
4
B,D
NLA - Insert, Non-Threaded Back Cane
(For Back Heights 21" and Higher)
1
2
5
Screw, Hex Head (1/4-20 x 1-5/8")
1
4
6
Washer (1/4 x 23/32 x 1/16")
1
4
7
Locknut (1/4-20)
1
4
8
Spacer, Coved (1/4 x 11/16 x 1/2")
1
4
9
A - Includes items 5-11
B - Includes items 5-9
C - Used for 12'-20" high back canes
D - Used for 21"-24" high back canes
E - Prior to 7/9/04 new back cane attaching hardware must be ordered for 12-15" deep seats that use CJ brackets. The
threaded insert was replaced with a non-threaded insert for 12-20" high back canes
