Tilt Link and Front Support Bracket
NOTE: The front actuator support bracket for a power elevating seat is located under the seat plate
assembly page.
NOTE: Tilt link mounting hardware is the same for a power tilt only and a power elevating seat.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1087634 Link, Tilt, Black 1 2 1
0139806 Screw, Hex Head (5/16-18 x 3") 1 1 2
1104258 Screw, Hex Head w/ Patch (5/16-18 x 1") 1 2 3
1023263-NLA NLA - Washer, Internal Tooth (M8) 1 3 4 C
1026158 Locknut (5/16-18) 1 1 5
1028769 Locknut (5/16-18) 1 4 6
1087613-NLA NLA - Bracket, Actuator Support, Front, Black (12 -
16" D) 1 1 7
1087622 Bracket, Actuator Support, Front, Black (17 - 19" D) 1 1 7
1087624-NLA NLA - Bracket, Actuator Support, Front, Black (20 -
22" D) 1 1 7
1107708 Screw, Shoulder Hex Socket Head (3/8 x 3/4",
5/16-18) 1 4 8
0139900 Washer, Nylon (1/2 x 3/4 x 3/32") 1 8 9
1087636-NLA NLA - Bushing, Bronze (3/8 x 1/2 x 1/2") 1 4 10
20105X000 Washer, Flat (1/4 x 5/8 x 1/16") 1 2 11
1106541-NLA NLA - Hardware, Tilt Link Mounting 1 1 12 A
1106542 Hardware, Front Actuator Support Bracket Mounting 1 1 13 B
A - Includes items 6 and 8-11
B - Includes items 2-5
C - Part #1023263 is no longer available as a service part individually. See item 13 and order part #1106542 as a
replacement.
NOTE:
16
