ABS Curved Back Assembly

NOTE: ABS curved back mounts only to Storm Series back canes without a 10 degree bend.

NOTE: As of 8/15/08 the Curved Back material changed from ABS Plastic to Metal as inventory runs out.

You must ask the customer if they have an ABS Plastic or the Metal Curved Back model when replacing

components. All service replacement Back Assemblies with Hardware shipped will be metal. New

Headrest Mounting Hardware is required when replacing an ABS Curved Back with a Metal Curved Back.

#1 Back Pan - 19" Wide to 22" Wide

Overall

Back Height

Material

Back Height

19" Wide

20" Wide

21" Wide

22" Wide

1086027-NLA

1086026-NLA

1086025-NLA

1086024-NLA

12"

16"

See Note(s) A

1086034-NLA

1086033-NLA

1086032-NLA

1086031-NLA

13"

17"

See Note(s) A

1086041-NLA

1086040-NLA

1086039-NLA

1086038-NLA

14"

18"

See Note(s) A

1086048-NLA

1086047-NLA

1086046-NLA

1086045-NLA

15"

19"

See Note(s) A

1086055-NLA

1086054-NLA

1086053-NLA

1086052-NLA

16"

20"

See Note(s) A

1086062-NLA

1086061-NLA

1086060-NLA

1086059-NLA

17"

21"

See Note(s) A

1086069-NLA

1086068-NLA

1086067-NLA

1086066-NLA

18"

22"

See Note(s) A

1086076-NLA

1086075-NLA

1086074-NLA

1086073-NLA

19"

23"

See Note(s) A

1086083-NLA

1086082-NLA

1086081-NLA

1086080-NLA

20"

24"

See Note(s) A

A - Part Number is No Longer Available. See Category page titled "Backs - Metal Curved Assembly" and use the item "Back
Assembly w/ Hardware" to find replacement part numbers. Match the wheelchair width by the material back height when ordering.

NOTE:

NOTE: Hook Fastener Adhesive Kit must be ordered when a Back Pan or Back Assembly is requested. This will allow the Loop Fastener
Adhesive on the Back Cover to attach properly.

To order call toll free 1-800-333-6900, or www.invacare.com

Form No. 01-038
