Arms, Adjustable Height
(12-13" W x 12-15" D) (14-15" W x 12-22" D) ASBA Seats
Item
Number Part Number Description Note
Quantity Per
Package Assembly
8881015932 Pad, Arm, Vinyl, Full Length - Right (14" L x 2" W) 1 1 1 A
8881015933 Pad, Arm, Vinyl, Full Length - Left (14" L x 2" W) 1 1 1 A
8881053577 Kit, Arm Pad w/ Screws, Full Length (14" L x 2" W)
(Pair) 2 1 1 A
8881011811 Pad, Arm, Vinyl, Desk Length (9" L x 2" W) 1 1 1 A,B
8881053578 Kit, Arm Pad w/ Screws, Desk Length (9" L x 2" W)
(Pair) 2 1 1 A,B
1071263 Arm Tube Assembly w/ Plug Buttons, Full Length,
Black - Right/Left 1 1 2
1071259 Arm Tube Assembly w/ Plug Buttons, Desk Length,
Black - Right/Left 1 1 2
1027095 Plug Button, Black (7/8") 1 2 3
1055949 Package, Screw, Phillips Pan Head (#10-32 x
1-1/8") (Pair) 2 1 4
47471X074 Spring, Arm Lock 1 1 5
1028594 Pin, Arm Lock, Black 1 1 6
1090768 Kit, Lock Handle w/Rivets (Pair) 2 1 7
1065936 Plug, Pivot 1 2 8
1067734 Plug Button, Black (5/8") 1 2 9
1016298 Grip, Push Handle 1 1 10
1068585 Arm Base Assembly, Adjustable Height, Black -
Right 1 1 11
1068586 Arm Base Assembly, Adjustable Height, Black - Left 1 1 11
A - Specify U67 black upholstery color when ordering.
B - It is recommended that full length arm pads be used for seat depths 12"-14" allowing proper arm pad exposure to support
the forearm of the customer
NOTE:
