ASBA Seat Mounting Hardware
(12"-15" Wide)
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1121054 Kit, 0 Degree 12-15 Wide ASBA Seat Mounting
Hardware 1 1 1 A
Screw, Hex Head w/ Patch (5/16-18 x 1-3/4") 1 4 2
Washer, Flat (5/16 x 5/8 x 1/16") 1 4 3
Locknut (5/16-18) 1 4 4
1107308 Kit, 0 Degree (12-15 Wide ASBA) & (12-16 Wide
ADJASBA) Seat Mounting Hardware 1 1 1 B
Screw, Hex Head (5/16-18 x 2") 1 4 2
Washer, Flat (5/16 x 5/8 x 1/16") 1 4 3
Locknut (5/16-18) 1 4 4
Plate, Spacer 1 1 5
1106544 Kit, Switch Clip with Mounting Hardware 1 1 6 C
Bracket, Cable/Wire Mounting, Black 1 1 7
Screw, Phillips Pan Head Tap (#10-16 x 3/4") 1 1 8
Lockwasher, External Tooth (#10) 1 1 9
1111007 Bumper with Mounting Hardware (Pair) 2 1 10
1088014 Kit, 5 Degree (12-15" Wide ASBA) & (12-16" Wide
ADJASBA) Seat Mounting Hardware 1 1 11 D
Screw, Hex Head w/ Patch (5/16-18 x 1-3/4") 1 2 12
Screw, Hex Head (5/16-18 x 3") 1 2 13
Washer, Flat (5/16 x 5/8 x 1/16") 1 8 14
Locknut (5/16-18) 1 4 15
Spacer (3/8 x 7/8 x 11/16") 1 2 16
A - Hardware Before 2/17/03 and includes items 2-4. A Spacer Plate was added after 2/16/03. When a new Seat Frame
Support is needed, Seat Mounting Hardware dated after 2/16/03 must be ordered.
B - Hardware After 2/16/03 and includes items 2-5
C - Includes items 7-9
D - Includes items 12-16
NOTE:
