Curve Contoura Back w/o Mounting Hardware - After
5/14/09
#3 Curve Contoura Back Cushion Assembly
Overall
Back
Height
Material
Back
Height
16" Wide 18" Wide 20" Wide 22" Wide
1166149 1166148 1166147 1166146
17" High 22" High
See Note(s) B See Note(s) B See Note(s) B See Note(s) B
1163254 1163252 1163250 1163248
20" High 25" High
See Note(s) B See Note(s) B See Note(s) B See Note(s) B
1163255 1163253 1163251 1163249
23" High 28" High
See Note(s) B See Note(s) B See Note(s) B See Note(s) B
B - Includes items 4 and 5. Back Cover and Foam are sold as a Back Cushion Assembly only. NOTE:
Overall Back Height includes the spacing gap dimension from the bottom of the Back Assembly to the Seat Pan
#3 Mesh Curve Contoura Back Cushion Assembly (CTBMSH)
Overall
Back
Height
Material
Back
Height
16" Wide 18" Wide 20" Wide 22" Wide
1166144 1166143 1166142 1166141
17" High 22" High
See Note(s) B See Note(s) B See Note(s) B See Note(s) B
1171648 1171646 1171644 1171642
20" High 25" High
See Note(s) B See Note(s) B See Note(s) B See Note(s) B
1171649 1171647 1171645 1171643
23" High 28" High
See Note(s) B See Note(s) B See Note(s) B See Note(s) B
B - Includes items 4 and 5. Back Cover and Foam are sold as a Back Cushion Assembly only. NOTE:
Overall Back Height includes the spacing gap dimension from the bottom of the Back Assembly to the Seat Pan
65
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-038
