MKIV TAC Controller and 4-Way Switch
without Elevating Seat
As of 7/1/2009, switches are mercury free.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1080634 Harness, Drive Lockout Mercury Free Ball Switch 1 2 1
1098915-NLA NLA - Controller, MKIV TAC 1 1 2
1025736 Locknut (1/4-20) 1 2 3
1007219 Screw, Socket Head (1/4-20 x 5/8") 1 2 4
1115465 Bracket, P.T.O./T.A.C. Mounting, Black 1 1 5
1026158 Locknut (5/16-18) 1 2 6
1070462 Screw, Hex Head w/ Patch (5/16-18 x 7/8") 1 2 7
1111050-NLA NLA - Controller w/ Hardware, MKIV TAC 1 1 8 A
1111050E Reconditioned - Controller w/ Hardware, MKIV TAC 1 1 8 A
1080116 Switch, 4-Way (FWT) 1 1 9
1077519 Kit, 4-Way Switch Joystick Tube Mounting
Hardware 1 1 10 C
Half Clamp, Threaded Holes 1 1 11
Half Clamp, Non-Threaded Holes 1 1 12
Bracket, Joystick Mounting, Black 1 1 13
Screw, Hex Head (1/4-20 x 1-1/8") 1 2 14
Washer (#10 Flat) 1 2 15
Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 16
1077520 Kit, 4-Way Switch Quad Link Mounting Hardware 1 1 10 B
Bracket, Quad Link Mounting, Black 1 1 13
Washer (#10 Flat) 1 2 15
Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 16
Locknut (#10-32) 1 2 17
Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 2 18
1139418 Kit, 4-Way Switch Quad Link Mounting Hardware 1 1 10 F
Screw, Phillips Pan Head w/Patch (#10-32 x 7/8") 1 2 19
Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 20
Washer, Nylon (#10) 1 2 21
Locknut (#10-32) 1 2 22
1134132 Bracket, 4-Way Switch Quad Link, Black - Right 1 1 23
1134133 Bracket, 4-Way Switch Quad Link, Black - Left 1 1 23
1026107 Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 2 18
1106544 Kit, Switch Clip with Mounting Hardware 1 1 D
Bracket, Cable/Wire Mounting, Black 1 1
Screw, Phillips Pan Head Tap (#10-16 x 3/4") 1 1
Lockwasher, External Tooth (#10) 1 1
