Invacare ESS-PTO - Manual (Page 31)

ASBA Seat Mounting Hardware
(16"-22" Wide) (Before 7/5/05)
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1107307 Kit, 0 Degree 16-22" Wide ASBA Seat Mounting
Hardware 1 1 1 A
Screw, Hex Head (5/16-18 x 2-3/4") 1 4 2
Washer, Flat (5/16 x 5/8 x 1/16") 1 4 3
Locknut (5/16-18) 1 4 4
1106544 Kit, Switch Clip with Mounting Hardware 2 1 5 B
Bracket, Cable/Wire Mounting, Black 1 1 6
Screw, Phillips Pan Head Tap (#10-16 x 3/4") 1 1 7
Lockwasher, External Tooth (#10) 1 1 8
1111007 Bumper with Mounting Hardware (Pair) 2 1 9
1087784 Kit, 5 Degree 16-22" Wide ASBA Seat Mounting
Hardware 1 1 10 C
Screw, Hex Head (5/16-18 x 2-3/4") 1 2 11
Screw, Hex Head (5/16-18 x 3-1/4") 1 2 12
Washer, Flat (5/16 x 5/8 x 1/16") 1 8 13
Locknut (5/16-18) 1 4 14
Spacer (3/8 x 7/8 x 11/16") 1 2 15
A - Includes items 2-4
B - Includes items 6-8
C - Includes items 11-15 NOTE:
30
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-038
