Table 8. Main Board External I/O Connectors
Board
Location
Connector
Description
E1
Serial
RS232C D-sub 9-pin serial port
E2
VGA
Mini D-sub 15-pin video port
E3
USB 0/1/2/3
USB Type A port x4
E4
GbE LAN 0/1
RJ45 LAN port x2
E5
100 MbE LAN
RJ45 LAN port x1
E6
100 MbE LAN
RJ45 LAN port x1 (for KVM)
Table 9. Main Board Internal I/O Connectors
Board Location
Connector
Description
C1~C4
CPU 0/1/2/3
mPGA700 ZIF sockets
C5/C8
PCI slot 1/4
x8 PCI-Express* slots
C6/C9
PCI slot 2/5
x16 PCI-Express slots
C7/C10
PCI slot 3/6
64-bit 133 MHz PCI-X* slots
C11~C14
VHDM 0/1/2/3
C15~C20
FAN 0/1/2/3/4/5
C21/C22
PS 0/1
C23
SAS
SFF-8484 (SAS internal x4 connector)
C24
ATA
40-pin IDE connector
C25
PNL
C26
PNLPW
C27/C28
MVR0/1, MVR2/3
C29
XDP
C30
KVM
C31
SATA
C32
IPMB
C33
DEBUG
