Installing and removing a processor, Figure 106. processor assembly components – Intel SR9000MK4U User Manual
Page 132
110
Intel
®
Server System SR9000MK4U Product Guide
Installing and Removing a Processor
Before beginning these steps, power down your server system and unplug all AC power
cords.
The following figure shows the components of the processor assembly. Refer to this figure
as needed during the installation process to identify the components discussed in this
section.
Figure 106. Processor Assembly Components
A.
Processor
D.
Spring shroud
B.
Heat sink
E.
Bolster plate
C.
Spring clip
F.
MVR
AF001249
A
F
E
D
C
B
