System Board Jumper Settings

For a more complete description of the function of these jumpers, see "Installing and
Removing Options" in the RS/6000 7046 Model B50 User's Guide.

Jumper

Description

Settings

J15

Remote Power-up

Default: Remote power-up disabled.

To enable Remote power-up, place
jumper on the two pins closest to the
rear of the server.

J20

Power-On Password

Default: power-on password enabled
(can be set).

To disable the power-on password
(for instance, if it has been forgotten),
place jumper on the two rightmost
pins.

J32

Privileged-Access Password

Default: disabled.

To enable the writing or changing of
the privileged-access password, place
jumper on the two pins closest to the
rear of the server.

J35, J36

SCSI Security

Default: external SCSI enabled

To disable external SCSI connector,
move the jumper on J35 to the front
two pins, and the jumper on J36 to
the right two pins.

1-8

7046 Model B50 Service Guide
