Specifications
The mechanical packaging, cooling, power supply, and environmental requirements
for the workstation are as follows:
Dimensions
In horizontal orientation, the dimensions are:
Height - 88.0 mm (3.5 inches)
Width - 447.0 mm (17.6 inches)
Depth - 612.0 mm (24.1 inches) Minimum
Depth - 751.8 mm (29.6 inches) Maximum (includes covers and cables)
Weight
14.5 kg (32 lb) Minimum to 15.9 kg (35 lb) Maximum
Maximum Support Capacity (Horizontal Position)
27.3 kg (60 lbs)
Operating Environment - Class C
Temperature - 10° to 40°C (50° to 104°F)
1
Humidity - 8% to 80% noncondensing
Wet Bulb - 27 degrees C (80 degrees F) operating and nonoperating
2
Maximum Altitude - 2135 m (7000 feet)
Power Source Loading
0.3k VA typical
0.5k VA maximum
1
The upper limit of the dry bulb temperature must be derated 1° C per 137m (450 ft.) above 915m (3000
ft.).
2
The upper limit of the wet bulb temperature must be derated 1° C per 274m (900 ft.) above 305m (1000
ft.).
1-4
7046 Model B50 Service Guide
