Cable Ties

After replacing the power supply, ensure that you attach cable ties at the areas
designated in the following diagrams:

P4

P3

100mm

P7

P5

Power
Supply
(Top View)

P6

25mm Max.

P8

Power
Supply
(Top View)

7-8

7046 Model B50 Service Guide
