Minolta PI4700E - Manual (Page 295)

9 Network Setting
9-10 Pi4700e
S
c
a
nner
M
ode
Ch
apte
r 9
LDAP Setting
LDAP Function Use this setting to turn LDAP search on or off.
The setting you make here does not go into effect until you turn
the copier off and then back on again.
The initial default setting is OFF.
LDAP Server Address Input the LDAP server address.
The initial default setting is blank.
Only an IP address can be typed in.
Port Number Enter the LDAP server port number.
The initial default setting is 389.
Search Root Input the search start point.
The initial default setting is blank.
Search Timeout(s) Input a timeout value (seconds) for LDAP communication.
The initial default setting is 60 seconds.
Max hit of Number Input a value that specifies the maximum number of hits that
can be accepted for LDAP search results.
The initial default setting is 100.
Anonymous Login Selecting this check box enables configuration of anonymous
login settings.
If the
Anonymous Login check box is selected, Login Name
and Password become unavailable.
Login Name(Dn) Input the user name.
Password Input the password.
Check LDAP settings Click this button to check whether the server can be accessed
(logged into) using the currently configured settings.
If the server is accessed but the settings are incorrect, an error
appears.
Refer to the “Error List” on page 11-6.
