8.10 Specifications
Network Card
10/100BaseT Cable
Be sure to use Category 5 shielded 10/100BaseT cable that conforms with
the pinouts shown below.
Dimensions 123.7 mm (L) × 95 mm (H)
Weight 225 g
Environmental Temperature: 0 to 50°C
Humidity: 5% to 80%
Buttons/Indicators Green LED, Amber LED (1 each)
Configuration Setup Onboard non-volatile memory
Connector: Ethernet RJ45 10/100Base T (8-wire)
Pin No. Color Ethernet
8 Blue/White
7 Blue
6 Orange/White Receive -
5 Green/White
4 Green
3 Orange Receive +
2 Brown/White Send -
1 Brown Send +
