SMARTRACK 116 IP
7
Long bracket x 2. (For increased rack
depth of 905 ~ 990mm)
Short bracket x 2
Bracket attachment x 2
Note! The short bracket and bracket attachment for a rack depth of 504~ 614 mm
and without a KVM switch connected to the drawer.
Flat screws x 6 (for rail mount to console body)
Screws x 6
Bracket A with thumbscrew x 2
Screws x4
Keys x 2.
5. Pre-installation guidelines
•
Switch off all computers
•
Place cables away from fluorescent lights, air conditioners, and machines that
are likely to generate electrical noise
•
Ensure that the maximum distance between each computer and the SmartRack
116 IP does not exceed 30m/100ft
