SMARTRACK 116 IP
57
M
IN
IC
O
M
M
IN
IC
O
M
ROCs
to servers
Update software
installed here
To Flash
connector
RS232 Download
cable
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
9
MINICOM
I
0
SMARTRACK 116IP SWITCH
FLASH
LAN
SERIAL
SMARTRACK 116IP SWITCH
Figure 59 RS232 Download cable
25.4 Starting and configuring the SmartRack 116 IP Update
1. Start the Update software by double-clicking the icon on your desktop
,
or choose Start/Programs/Smart CAT5 Switch Update/ Smart CAT5 Switch
Update. The Smart CAT5 Switch Update window appears. See Figure 60.
Where the ROCs do not appear, select Options/Get RICCs.
Smart 116 IP
Switch
RoC /
RICCs
Status bar
Figure 60 Update window
