-84-
G0554 Gear-Head Floor Lathe
REF PART # DESCRIPTION REF PART # DESCRIPTION
1100 P05541100 FOLLOW REST COMPLETE ASSY 1401 P05541401 WORK LIGHT
1101 P05541101 HANDLE 1401-1 P05541401-1 LIGHT SOCKET
1102 PSS02M SET SCREW M6-1 X 6 1402 PS15M PHLP HD SCR M6-1 X 14
1103 P05541103 BUSHING 1403 P05541403 LAMP BRACKET
1104 P05541104 SPECIAL SCREW 1404 PSB02M CAP SCREW M6-1 X 20
1105 P05541105 SLEEVE 1405 P05541405 CONNECTED TUBE
1106 P05541106 BRASS FINGER 1406 P05541406 COOLANT DEVICE (PLASTIC)
1107 PN01M HEX NUT M6-1 1407 P05541407 RUBBER TUBE
1108 PSS25M SET SCREW M6-1 X 20 1408 PSB38M CAP SCREW M5-.8 X 25
1109 P05541109 BODY CASTING 1409 P05541409 COOLANT PUMP
1110 PSB35M CAP SCREW M8-1.25 x 60 1410 P05541410 WATER TANK
1200 P05541200 THREADING DIAL ASSY 1411 PN06M HEX NUT M5-.8
1201 P05541201 DIAL 1412 P05541412 TOOLBOX
1202 PRP61M ROLL PIN 3 X 12 1413 P05541413 TOUCH-UP PAINT
1203 P05541203 SHAFT 1414 P05541414 OIL CAN
1204 PRP42M ROLL PIN 3 X 20 1415 PSDS2 #2 STANDARD SCREWDRIVER
1205 P05541205 GEAR 32T 1416 PSDP2 #2 PHILLIPS SCREWDRIVER
1206 P05541206 BODY 1417 P05541417 THREE-JAW CHUCK*
1207 PSB30M CAP SCREW M6-1 X 45 1418 PWR911 OPEN-END WRENCH 9/11MM
1208 P05541208 NAME PLATE 1418-1 PWR1012 COMBO WRENCH 10/12MM
1209 PS12M PHLP HD SCR M3-.5 X 6 1418-2 PWR1214 COMBO WRENCH 12/14MM
1210 P05541210 RIVET 2 X 4 1418-3 PWR1417 WRENCH 17/14MM
1300 P05541300 COMPLETE STEADY REST 1419 PAW02.5M HEX WRENCH 2.5MM
1301 P05541301 HANDLE 1419-1 PAW03M HEX WRENCH 3MM
1302 PSS02M SET SCREW M6-1 X 6 1419-2 PAW04M HEX WRENCH 4MM
1303 P05541303 BUSHING 1419-3 PAW05M HEX WRENCH 5MM
1304 P05541304 SPECIAL SCREW 1419-4 PAW06M HEX WRENCH 6MM
1305 P05541305 SLEEVE 1419-5 PAW08M HEX WRENCH 8MM
1306 P05541306 BRASS FINGER 1420 P05541420 MT#5-3 TAPERED SLEEVE
1307 P05541307 UPPER BODY CASTING 1421 P05541421 MT#3 DEAD CENTERS
1309 PSS25M SET SCREW M6-1 X 20 1422 P05541422 CHANGE GEARS 30T
1310 PN01M HEX NUT M6-1 1422-1 P05541422-1 CHANGE GEARS 32T
1311 P05541311 LOWER BODY CASTING 1422-2 P05541422-2 CHANGE GEARS 40T
1312 P05541312 LOCK PIN 1423 P05541423 TOOL POST WRENCH
1313 P05541313 LOCK BOLT M8-1.25 1424 P05541424 3-JAW CHUCK KEY
1314 PN09M HEX NUT M12-1.75 1425 P05541425 SPINDLE LOCK KEY
1315 PW06M FLAT WASHER 12MM 1426 P05541426 8" FOUR JAW CHUCK
1316 P05541316 CLAMP PLATE 1427 P05541427 FOUR JAW CHUCK KEY
1317 PB43M HEX BOLT M12-1.75 X 75 1428 P05541428 CAMLOCK STUD
1318 PW01M FLAT WASHER 8MM 1429 P05541429 CAMLOCK STUD SET SCREW
1319 P05541319 KNOB M8-1.25 1430 P05541430 CAST IRON FOOT PAD
1400 P05541400 WORK LIGHT COMPLETE ASSY 1431 P05541431 12" FACE PLATE
* NOT SHOWN IN PARTS BREAKDOWN
Coolant, Worklight, Boxes, Thread Dial,
Steady & Follow Rest Parts List
