-4-
G0554 Gear-Head Floor Lathe
The information contained herein is deemed accurate as of 5/26/2006 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 3 Model G0554
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0554 14" X 40" LATHE
Product Dimensions:
Weight............................................................................................................................................................ 2191 lbs.
Length/Width/Height....................................................................................................................... 80 x 29-1/2 x 45 in.
Foot Print (Length/Width)....................................................................................................................... 73-1/2 x 19 in.
Shipping Dimensions:
Type........................................................................................................................................................... Wood Crate
Content............................................................................................................................................................ Machine
Weight............................................................................................................................................................ 2738 lbs.
Length/Width/Height............................................................................................................................. 77 x 30 x 59 in.
Electrical:
Switch........................................................................................... Magnetic Switch with Thermal Overload Protection
Switch Voltage...................................................................................................................................................... 220V
Recommended Breaker Size............................................................................................................................ 20 amp
Plug.......................................................................................................................................................................... No
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................3 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................Single
Amps.............................................................................................................................................................14A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ...................................................................................................................... Belt Drive to Gear
Bearings........................................................................................................... Shielded and Lubricated for Life
Main Specifications:
Operation Info
Swing Over Bed......................................................................................................................................... 14 in.
Dist Between Centers.................................................................................................................................40 in.
Swing Over Cross Slide......................................................................................................................... 8-1/2 in.
Swing Over Saddle................................................................................................................................ 8-1/2 in.
Swing Over Gap......................................................................................................................................... 20 in.
Max Tool Bit Size...................................................................................................................................... 5/8 in.
Compound Travel...................................................................................................................................3-1/2 in.
Carriage Travel.................................................................................................................................... 37-1/2 in.
Cross Slide Travel........................................................................................................................................ 7 in.
M
