G0554 Gear-Head Floor Lathe
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0554001 PLUG 51 P0554051 SHAFT
2 P0554002 HEADSTOCK COVER 52 P0554052 SHAFT
3 PSB48M CAP SCREW M6-1 X 35 53 PK05M KEY 4 X 4 X 10
4 P0554004 GASKET 54 P0554054 O-RING 12.6 X 2.65
5 P0554005 O-RING 55 P0554055 COLLAR
6 P0554006 GEAR 38T 56 PSB26M CAP SCREW M6-1 X 12
7 P05540107 SHAFT 57 P0554057 COLLAR
8 PSS01M SET SCREW M6-1 X 10 58 P0554058 HANDLE BODY
9 PSS02M SET SCREW M6-1 X 6 59 PW03M FLAT WASHER 6MM
10 P0554010 GEAR 48T 60 P0554060 INDICATOR DISC
11 P0554011 GEAR 43T 61 PSB14M CAP SCREW M8-1.25 X 20
12 PSS15M SET SCREW M12-1.75 X 12 62 PW01M FLAT WASHER 8MM
13 P0554013 SHIFT ARM 63 P0554063 PULLEY
14 PRP05M ROLL PIN 5 X 30 64 P0554064 BREAK BLOCK
15 PR03M EXT RETAINING RING 12MM 65 PRP24M ROLL PIN 5 X 16
16 P0554016 SHIFT FORK 66 P0554066 BREAK ACTUATOR SHAFT
17 P0554017 SHIFT ARM 67 PR03M EXT RETAINING RING 12MM
18 P0554018 GEAR SHIFTER 68 P0554068 SPACER SD 25 X 45 X 7
19 P0554019 PLUG 69 PRP46M ROLL PIN 6 X 28
20 PK08M KEY 5 X 5 X 16 70 PR39M EXT RETAINING RING 8MM
21 P0554021 STEEL BALL 71 P0554071 BRAKE RETAINER STUD
22 P0554022 COMPRESSION SPRING 72 P0554072 COVER
23 P0554023 HANDLE BODY 73 P0554073 GASKET
24 P0554024 HANDLE CAP 74 PR11M EXT RETAINING RING 25MM
25 P0554025 HANDLE LEVER 75 P6205 BALL BEARING 6205ZZ
26 P0554026 LEVER NAME PLATE 76 PK107M KEY 8 X 8 X 20
27 PS12M PHLP HD SCR M3-.5 X 6 77 P0554077 SHAFT
28 PW03M FLAT WASHER 6MM 78 P0554078 KEY 8 X 8 X 72
29 PSB26M CAP SCREW M6-1 X 12 79 P0554079 GEAR 50T
30 P0554030 POSITION PLATE 80 P0554080 GEAR 37T
31 P0554031 O-RING 81 P0554081 GEAR 43T
32 P0554032 GEAR SHAFT 22T 82 P6204 BALL BEARING 6204ZZ
33 P0554033 GEAR SHAFT 17T 83 PW13M FLAT WASHER 20MM
34 P0554034 POSITION PLATE 84 P0554084 GEAR 57T
35 P0554035 HANDLE BODY 85 P0554085 GEAR SHAFT
36 PSB111M CAP SCREW M12-1.75 X 35 86 PR25M INT RETAINING RING 47MM
37 P0554037 ALIGNMENT BOLT M10 X 40 87 P0554087 O-RING 40 X 2.65
38 P0554038 ALIGNMENT BOLT M12 X 17 88 P0554088 PLUG
39 P0554039 ALIGNMENT BLOCK 89 P0554089 BEARING CAP
40 P0554040 OIL SIGHT GLASS 90 P0554090 BEARING CAP GASKET
41 P0554041 HEADSTOCK CASTING 14" 91 P0554091 GEAR 28T
42 P0554042 DRAIN PLUG 92 PK121M KEY 8 X 8 X 38
43 P0554043 GEAR SHAFT 27T 93 P0554093 GEAR 41T
44 P0554044 SHAFT FORK 94 P0554094 GEAR 34T
45 P0554045 SHIFTING CRANK 95 PR68M EXT RETAINING RING 40MM
46 P0554046 SHAFT FORK 96 P6005 BALL BEARING 6005ZZ
47 P0554047 SHIFTING CRANK 97 P0554097 GEAR SHAFT 21T
48 P0554048 STEEL BALL 9 98 PR18M EXT RETAINING RING 17MM
49 P0554049 COMPRESSION SPRING 99 P0554099 BALL BEARING 61803/P5
50 P0554050 SHAFT 100 P0554100 GEAR 21T
Headstock Parts List
