Grizzly G0554 - Manual (Page 79)

G0554 Gear-Head Floor Lathe
-77-
REF PART # DESCRIPTION REF PART # DESCRIPTION
801 PS39M PHLP HD SCR M8-1.25 X 10 832 PN01M HEX NUT M6-1
802 P0554802 ELECTRICAL BOX COVER 833 PSS25M SET SCREW M6-1 X 20
803 PN03M HEX NUT M8-1.25 834 PRP42M ROLL PIN 3 X 20
804 P0554804 STUD 835 P0554835 CONTROL FORK
805 P0554805 ELECTRICAL PLATE 836 P0554836 CONTROL HANDLE
806 P0554806 GAP 837 P0554837 HANDLE
807 PSB92M CAP SCREW M12-1.75 X 40 838 PSB01M CAP SCREW M6-1 X 16
808 PN03M HEX NUT M8-1.25 839 P0554839 CONTROL BRACKET
809 PRP48M ROLL PIN 8 X 60 840 P0554840 DOWEL PIN
810 P0554810 BED 841 P0554841 COMPRESSION SPRING
811 PB51M HEX BOLT M16-2 X 50 842 PSS20M SET SCREW M8-1.25 X 8
812 PSB06M CAP SCREW M6-1 X 25 843 P0554843 COMPRESSION SPRING
813 PRP10M ROLL PIN 5 X 36 844 P0554844 SLEEVE
814 P0554814 RACK (LONG) 845 P0554845 SPINDLE CONTROL SHAFT
815 P0554815 RACK (SHORT) 846 PSS45M SET SCREW M3-.5 X 6
816 P0554713 OILER 10 847 PK119M KEY 5 X 5 X 56
817 P0554817 PLUG 848 PSS01M SET SCREW M6-1 X 10
818 P0554818 PLUG 849 P0554849 COLLAR
819 PSB60M CAP SCREW M8-1.25 X 55 850 P0554850 SHIFT COLLAR
820 PRP48M ROLL PIN 8 X 60 851 PSS11M SET SCREW M6-1 X 16
821 P0554821 END BRACKET 852 P0554852 DOWEL PIN
822 P51104 THRUST BEARING 51104 853 P0554853 DOWEL PIN
823 PSS16M SET SCREW M8-1.25 X 10 854 P0554854 INDEX RING
824 P0554824 COLLAR 855 PRP14M ROLL PIN 3 X 6
825 P0554825 LEADSCREW M22 X 3.175 856 P0554856 SHAFT
826 PRP10M ROLL PIN 5 X 36 857 P0554857 BRACKET
827 P0554827 COLLAR 858 PSS04M SET SCREW M6-1 X 12
828 P0554828 FEED SHAFT 859 P0554859 PLATE
829 P0554829 COMPRESSION SPRING 860 PSB01M CAP SCREW M6-1 X 16
830 P0554410 STEEL BALL 6 861 PRP10M ROLL PIN 5 X 36
831 P0554831 CLUTCH
Bed Parts List
