Identification – Grizzly G0554 User Manual
Page 8
-6-
G0554 Gear-Head Floor Lathe
Figure 1. The Model G0554 Gear-Head Floor Lathe.
A. Headstock
B. Spindle
C. Three-Jaw Chuck
D. Tool Post
E. Work Light
F. Coolant Hose
G. Dead Center
H. Quill
I. Quill Lock
J. Tailstock Lock
K. Splash Guard
Identification
A
L. Tailstock
M. Tailstock Handwheel
N. Bed Ways
O. Bed
P. Gap Bed
Q. Rack
R. Longitudinal Lead Screw
S. Feed Rod
T. Power Control Rod
U. Coolant Reservoir Cover
V. Foot Brake
O
B
C
E
D
P
F
G H I
J
K
L
M
N
Q
R
S
T
U
V
