Inventory
After all the parts have been removed from the
two boxes, you should have the following items:
Main Crate: (Figures 5 & 6) Qty
A. Model G0554 Gear Head Lathe ................. 1
B. 12" Faceplate ............................................. 1
Figure 5. Main Inventory.
Large Wooden Box: (Figure 6) Qty
C. 8" Four Jaw Chuck ..................................... 1
D. Four Jaw Chuck Key .................................. 1
E. Camlock Studs ........................................... 3
F. Camlock Stud Set Screws .......................... 3
Small Wooden Box: (Figure 6) Qty
G. Cast Iron Foot Pads ................................... 6 In the event that any nonproprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or for the sake of expedi-
ency, replacements can be obtained at your local
hardware store.
Figure 7. Tool Box Inventory.
A
B
C
D
E
F
G
H
I J
K
L
M
N
O
P Q
R
S
T
U
NOTICE
Some hardware/fasteners on the inventory
list may arrive pre-installed on the machine.
Check these locations before assuming that
any items from the inventory list are miss-
ing.
Tool Box: (Figure 7) Qty
H. Tool Box ..................................................... 1
I. Touch-up Paint ........................................... 1
J. Oil Can ....................................................... 1
K. Slotted Screwdriver .................................... 1
L. Phillips Head Screwdriver #2 ..................... 1
M. Handwheel Handles ................................... 2
N. Open End Wrenches 9/11, 10/12, 12/14,
17/14mm ........................................... 1 each
O. Hex Wrenches 2.5, 3, 4, 5, 6, & 8mm ..........
.......................................................... 1 each
P. MT#5-3 Tapered Sleeve ............................ 1
Q. MT#3 Dead Centers ................................... 2
R. Change Gears 30T, 32T, 40T (2) ...... 1 each
S. Tool Post Wrench ....................................... 1
T. 3-Jaw Chuck Key ....................................... 1
U. Spindle Lock Key ....................................... 1
