Carriage parts list – Grizzly G0554 User Manual
Page 73
G0554 Gear-Head Floor Lathe
-71-
Carriage Parts List
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
501
P0554501
GIB
533
PS09M
PHLP HD SCR M5-.8 X 10
502
P0554502
GIB ADJUSTING SCREW M6 X 23
534
P0554534
INDEX RING
503
PS09M
PHLP HD SCR M5-.8 X 10
535
P0554535
COMPOUND HANDLE HUB
504
P0554504
PLATE
536
P0554536
COVER SCREW M12 X 7
505
P0554505
PLATE WIPER
537
PSS12M
SET SCREW M6-1 X 25
506
P0554506
CROSS SLIDE BODY
538
P0554538
HANDLE LEVER
507
P0554507
CLAMP NUT M8
539
P0554539
HANDLE SLEEVE
508
P0554508
HUB
540
P0554540
COMPRESSION SPRING
509
P0554509
OILER 8
541
P0554410
STEEL BALL 6
510
PSB02M
CAP SCREW M6-1 X 20
542
P0554542
SADDLE
511
P0554511
SLEEVE
543
PRP32M
ROLL PIN 6 X 40
512
PSS20M
SET SCREW M8-1.25 X 8
544
P0554544
PLATE WIPER
513
PN02M
HEX NUT M10-1.5
545
PS09M
PHLP HD SCR M5-.8 X 10
514
P0554514
BEARING CAP
546
P0554546
PLATE
515
PSB07M
CAP SCREW M6-1 X 30
547
PSB12M
CAP SCREW M8-1.25 X 40
516
P8101
THRUST BEARING 8101
548
P0554548
OILER
517
P0554517
BLOCK
549
P0554549
PLATE
518
P0554518
SPACER
550
P0554550
PLATE WIPER
519
P0554519
LEADSCREW M15 X 2.54
551
P0554551
REAR PRESSURE PLATE
520
PSB26M
CAP SCREW M6-1 X 12
552
P0554552
GIB
521
P0554521
CROSSFEED NUT M15.5 X 2.54
553
PLN03M
LOCK NUT M6-1
522
PS49M
PHLP HD SCR M3-.5 X 5
554
PSS25M
SET SCREW M6-1 X 20
523
PK23M
KEY 5 X 5 X 25
555
PSB14M
CAP SCREW M8-1.25 X 20
524
P0554524
GEAR SHAFT
556
P0554556
HANDLE KNOB M10 X 50
525
PK48M
KEY 4 X 4 X 20
557
P0554557
HANDLE SHAFT
526
P0554526
OILER 6
558
P0554558
HUB
527
PS12M
PHLP HD SCR M3-.5 X 6
559
P0554559
OIL CAP
528
P0554528
INDICATOR LABEL
560
P0554560
LOCK STUD
529
P0554529
HOUSING
561
P0554561
FRONT PRESSURE PLATE
530
PSB29M
CAP SCREW M6-1 X 40
562
P0554562
CONNECTED TUBE
531
P8102
THRUST BEARING 8102
563
P0554563
LAMP BRACKET
532
PW08M
FLAT WASHER 16MM
