Apron parts list – Grizzly G0554 User Manual
Page 71
G0554 Gear-Head Floor Lathe
-69-
Apron Parts List
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
400
P0554400
COMPLETE APRON ASSY
440
P0554440
COLLAR
401
PSB04M
CAP SCREW M6-1 X 10
441
PRP10M
ROLL PIN 5 X 36
402
P0554402
HALF NUT M23 X 3.175
442
P0554442
GEAR 24T
403
P0554403
BRACKET
443
PSS02M
SET SCREW M6-1 X 6
404
PSB01M
CAP SCREW M6-1 X 16
444
PK20M
KEY 5 X 5 X 15
405
P0554405
GIB
445
P0554445
SHAFT
406
PSS01M
SET SCREW M6-1 X 10
446
P0554446
O-RING 17 X 1.8
407
PSB12M
CAP SCREW M8-1.25 X 40
447
PR03M
EXT RETAINING RING 12MM
408
PSS20M
SET SCREW M8-1.25 X 8
448
P0554448
BUSHING
409
P0554409
COMPRESSION SPRING 6 X 42
449
P0554449
COLLAR
410
P0554410
STEEL BALL 6
450
P0554450
CLUSTER GEAR 50T/20T
411
P0554411
CASTING
451
PSS20M
SET SCREW M8-1.25 X 8
412
P0554412
DOWEL PIN
452
P0554452
COMPRESSION SPRING 6 X 22
413
P0554413
HALF NUT CAM 16 X 75
453
P0554410
STEEL BALL 6
414
PRP10M
ROLL PIN 5 X 36
454
P0554454
SHAFT
415
PSS02M
SET SCREW M6-1 X 6
455
P0554455
SHAFT
416
PRP30M
ROLL PIN 5 X 50
456
PRP05M
ROLL PIN 5 X 30
417
P0554417
HUB
457
P0554457
GEAR 50T
418
P0554418
HANDLE SHAFT
458
P0554458
BUSHING
419
P0554419
KNOB
459
PR06M
EXT RETAINING RING 16MM
420
P0554420
SAFETY CATCH
460
P0554460
PLUG
421
P0554421
SIGHT GLASS 12
461
P0554461
SHAFT
422
P0554422
BRACKET
462
PK20M
KEY 5 X 5 X 15
423
P0554423
BLOCK
463
P0554463
WHEEL FLANGE
424
PSB26M
CAP SCREW M6-1 X 12
464
PSB01M
CAP SCREW M6-1 X 16
425
P0554425
SPLINE SHAFT
465
P0554465
INDICATOR RING
426
P0554426
HANDLE SHAFT
466
P0554410
STEEL BALL 6
427
PSB30M
CAP SCREW M6-1 X 45
467
P0554467
COMPRESSION SPRING 6 X 12.6
428
P0554428
PLUG
468
P0554468
WHEEL
429
PSB01M
CAP SCREW M6-1 X 16
469
PSS12M
SET SCREW M6-1 X 25
430
P0554430
DRAIN PLUG
470
P0554470
WHEEL STUD
431
P0554431
FLANGE
471
P0554471
HANDLE SLEEVE
432
PK119M
KEY 5 X 5 X 56
472
P0554472
HANDLE LEVER
433
PRP14M
ROLL PIN 3 X 6
473
PSS05M
SET SCREW M5-.8 X 10
434
P0554434
WORM
474
P0554474
O-RING 25.8 X 3.55
435
P0554435
COLLAR
475
P0554475
APRON LABEL
436
P0554436
BUSHING
476
PS12M
PHLP HD SCR M3-.5 X 6
437
P0554437
SHAFT
477
P0554477
THREAD DIAL LABEL
438
PR06M
EXT RETAINING RING 16MM
478
P0554478
INDICATOR LABEL
439
P0554439
GEAR 22T
