Features of GE Large Faceplate Wizards
PMCS Interface Toolkit
Feature
Function
STORE Button
Resets the meter at two special points in the display of values.
Press STORE to toggle the response on the bottom line.
PAGE Buttons
Rotate among seven pages of parameter data. Press one of the
arrow keys to display PAGE #: ACTUAL VALUES on the top
line, a description on the bottom, and reset to the first parameter
value. The seven pages are listed in the following tables.
LINE Buttons
Rotate among parameters within a page. Certain configurations
or meter values may prevent display of all parameters within a
page. The parameters in each page are listed in the table below.
Panel Display
Lights
Display animation that shows the status of the 269 Plus relay. If a
trip or alarm has occurred, auxiliary relay 1 or 2 is active. If the
meter fails its self-test, the dark red square to the left of the label
appears bright red.
Table 14. 269+ Faceplate animated functions.
The following table lists the pages that can be accessed with the PAGE buttons, with
the parameters available in each page that can be accessed with the LINE buttons.
Page
Value
Text Displayed
Description
1
PAGE 1: ACTUAL VALUES
PHASE CURRENT DATA
Page header
2
I1=xxx I2=xxx
I3=xxx (AMPS)---
Phase current in amps; --- or RUN based on
motor status
3
I(3 Ph avg.)=xxx AMPS
Max Stator RTD=xxx C
Average phase current
Hottest stator temperature
1
4
UNBALANCE RATIO (In/Ip)
U/B=xx PERCENT
5
GROUND FAULT CURRENT
G/F=xxx.0 AMPS
Units = *.1 if G/F CT
ratio = 2000:1
6
ST/HR TIMERS (MIN)
xx xx xx xx xx
Starts per hour
7
TIME BETWEEN STARTS
TIMER = xxx MIN
8
END OF PAGE ONE
ACTUAL VALUES
Page footer
1
PAGE 2: ACTUAL VALUES
RTD TEMPERATURE DATA
Page header
2
HOTTEST STATOR RTD
RTD #xx = xxx
3-12
RTD TEMPERATURE
RTD # xx = xxx
Displays temperatures of RTDs #1-10
2
13
MAX STATOR SINCE LAST
ACCESS: RTD #x = xxx DEGREES C
14-17
MAXIMUM RTD #x TEMP SINCE
LAST ACCESS: xxx DEGREES C
Displays #7-10 max
18
CLEAR LAST ACCESS DATA?
NO
Press STORE to clear; message changes to
YES
19
END OF PAGE TWO
ACTUAL VALUES
Page footer
