104
•
Features of GE Large Faceplate Wizards PMCS Interface Toolkit
Page Value Text Displayed Description
1 ACTUAL VALUES
VOLTAGE Page header
2 VOLTAGE A-B
xxx.xx kV
6 3 VOLTAGE B-C
xxx.xx kV
4 VOLTAGE C-A
xxx.xx kV
5 FREQUENCY OF
FEEDER xxx.xx Hz
6 VOLTAGE
END OF PAGE Page footer
1 ACTUAL VALUES
EVENT Page header
2 NO OF EVENTS
xxx
or
EVENT RECORDING
DISABLED
Displayed only if enabled
7 3 CLEAR EVENTS?
NO Press STORE button to clear event counter
4 EVENTS CLEARED
LAST: xx/xx/xx Date of last reset: mm/dd/yy
5 EVENT
END OF PAGE Page footer
1 ACTUAL VALUES
DEMAND DATA Page header
2 PH-A PEAK DEMAND
xxx A
or
AMPS DEMAND
DISABLED
Value in amps
or
Next prompt is CLEAR AMP DEMAND
3 PH-B PEAK DEMAND
xxx A Value in amps
4 PH-C PEAK DEMAND
xxx A Value in amps
5 CLEAR AMP DEMAND
DATA? NO Press STORE button to reset amp data
6 DATA CLEARED
LAST: xx/xx/xx Date of last reset: mm/dd/yy
8 7 PEAK KW DEMAND
xxx kW
or
KW DEMAND
DISABLED
or
Displayed if disabled
8 CLEAR KW DEMAND
DATA? NO Press STORE button to reset kilowatt data
9 KW DEMAND DATA
CL’D: xx/xx/xx Date of last reset: mm/dd/yy
