PMCS Interface Toolkit
Features of GE Large Faceplate Wizards
•
83
Display Indication
Parameters
B,
Phase B current and B-C line-to-line voltage
C,
Phase C current and C-A line-to-line voltage
*,
Average current line-to-line voltage
The parameters displayed by the FUNCTION button are listed in the following table.
When any of the import, export, or net parameters are displayed, the AMPS portion
of the display window is used to allow display of the complete value.
Display Indication
Parameter
kW
Real power for phase A, B, or C as set by PHASE button, or
total real power if PHASE is set to * or *,.
kVR
Reactive power for phase A, B, or C as set by PHASE button, or
total reactive power if PHASE is set to * or *,.
kVA
Apparent power for phase A, B, or C as set by PHASE button,
or total apparent power if PHASE is set to * or *,.
PFLG or PFLD
Power factor, lagging or leading, for phase !A, B, or C as set by
PHASE button, or total power factor if PHASE is set to * or *,.
I4
RMS neutral current
Hz
Frequency
VX
RMS auxiliary voltage
kWH IM
Import energy
kWH EX
Export energy
kVARH IM
Import reactive energy
kVARH EX
Export reactive energy
kVAH NET
Net reactive energy
