Magnum 6K32T & 6K32TRC Managed Switch Installation and User Guide(05/07)
iv
www GarrettCom com . .
4.4 Flow-control, IEEE 802.3x standard.................................................. 49
5.0 6K32T & 6K32TRC MANAGED SWITCH PORT MODULES..... 49
5.1 Inspecting the Package and Product ................................................... 50
5.2 6KPM Module Description ................................................................ 50
5.2.1 6KP6-RJMST multi-mode FX-ST “twist lock” Module ............ 51
5.2.1a 6KP6-RJ10ST multi-mode FX-ST “twist lock” Combo ............ 51
5.2.1b 6KP4-F10ST multi-mode FX-ST “twist lock” Module............. 52
5.2.1c 6KP4-FLSTFX multi-mode FX-ST “twist lock” Module ......... 52
5.2.2. 6KP6-RJMSC multi-mode FX-SC “snap-in” Fiber connector ........... 53
5.2.3 6KP6-RJSSC Mbps single-mode FX-SC-type, “snap-in” .................. 54
5.2.4 6KP6-RJSSCL FX-SC-type, “snap-in” connector ............................ 54
5.2.4a 6KP6-RJ10ST FL-ST-type, “twist-lock” connector ........................... 55
5.2.5 6KP8-MTRJJ Small-Form-factor............................................... 55
5.2.5a 6KP6-MT10STmode FX Factor ................................................ 56
5.2.6 6KP8-45MT MTRJ Small-Form-Factor..................................... 57
5.2.7 6KP8-MLC LC connector Small- .............................................. 57
5.2.8 6KP8-45LC 10/100 Mbps RJ-45 Connector .............................. 58
5.2.9 6KP8-RJ45 (Twisted Pair), 10/100Mb 8-Port........................... 58
5.2.10a. New PoE (Power Pass-through)P6KP8V-RJ45 (MDIX) ................. 59
5.2.10b. New PoE(Power Inside), model PI6KP8-45RJ (MDIX) ................. 60
5.2.11 6KP8-45-2MT MTRJ Small-Form-Factor ................................ 62
5.2.11a 6KP8-45-2LC single-mode FX , LC Small-Form-Factor....... 62
5.2.12 GBIC-SXSC Gigabit fiber(1000Mb), multi-mode SC .............. 62
5.2.12a GBPM-2OTX (Two Gigabit option) ...................................... 63
5.2.12b GBIC-LXSC Gigabit fiber (1000Mb), multi-mode SC ......... 64
5.2.13 6KM-BLNK ............................................................................... 64
6.0 TROUBLESHOOTING....................................................................... 65
6.1 Before Calling for Assistance............................................................. 65
6.2 When Calling for Assistance.............................................................. 66
6.3 Return Material Authorization (RMA) Procedure.............................. 66
6.4 Shipping and Packaging Information ................................................. 67
APPENDIX A: WARRANTY INFORMATION ......................................... 67
APPENDIX B : INTERNAL DC POWER SUPPLY OPTIONS ................. 68
APPENDIX C: INTERNAL DC DUAL-SOURCE POWER OPTION ...... 71
Revisions
Rev C 05/07: SFP fiber info added and Typo error updated on Temp.
Rev C 10/06: Included 6K32TRC and PoE Modules
Rev B 12/05 : Updated Gigabit options
Rev A 05/05 : Minor updates, Auto-Cross(MDIX)
Rev A 02/05 : Minor updates and tweak on LC connector diagram
Rev A 08/04 : This revision is the initial release of the 6K32T manual.
