Magnum 6K32T & 6K32TRC Managed Switch Installation and User Guide 05/07)
22
www GarrettCom com . .
„ MNS-6K licensed Network Management Software included, S-Ring/RS-Ring
optional
Release 3.5 (summer ’06) includes SNMP, Secure Web Management, RMON, CLI,
Port Security; Port Mirroring; Port Settings Control; Telnet, TFTP, FTP support,
Spanning Tree Protocol, RSTP, LLL, S-Ring Redundancy Mgr, (optional) multi-level
QoS, Port and Tag-based VLANs, GVRP, IGMP Snooping, SNMPc GUI support;
BootP and DHCP client for IP configuring, Radius X, TACACS+ etc.
„ MDI-MDIX Auto-negotiating on RJ-45 ports for convenient cascading using
straight RJ-45 cable.
„ Support PoE module to provide power via RJ-45 cable on the modular slot.
2.4 Applications
Magnum 6K32T & 6K32TRC Fiber Switches offer high performance along
with one or two modular slot options to fulfill the choice of copper/Fiber, 10,100 or
1000Mb requirements. The 6K32T & 6K32TRC also offers MNS-6K management
software loaded with multiple useful features. The Magnum IEC61850 6K32T &
6K32TRC Switches are used in a variety of Power sub-stations applications including,
Industrials and temp. un-controlled, secure VLAN- performance upgrades to
departmental networks, and LAN traffic centers that require Gigabit backbone services.
The performance characteristic of the 6K32T & 6K32TRC Switches enables them to
inter-connect a series of subnets (one subnet per 6K32T Switch port) in a LAN traffic
center. The subnet connections may be via fiber or twisted pair cabling, 100Mbps or 10
Mbps speed, and full-or half-duplex mode.
The mixed-media capability in the modular slot is ideal for upgrading existing
Ethernet LAN networks where existing cabling must be accommodated. The fiber-built-
in media capability provides future-proof fiber cabling for the LAN structure. The
secured management features offer a multiple options to provide a secure Network
solution.
Example 1 : Magnum 6K32T Switch for a VLAN application
Equipped with lots of advanced management features, the Magnum 6K32T
Managed switch is able to handle a VLAN application and provide security and
performance in an Ethernet network center. A secure VLAN-enabled network is simply
an administratively-configured broadcast domain. The network administrator determines
which ports and nodes are in which broadcast domains by setting membership profiles
