Magnum 6K32T & 6K32TRC Managed Switch Installation and User Guide 05/07)
6
www GarrettCom com . .
6KP8-45-2SLC “6+2” module, w/six RJ-45 ports and two 100Mb 15km sgl. mode FX
LC connectors
Gigabit Options (Modules using GBIC)
6KP5-G4RJ “G+4” module, with one GBIC open transceiver and four 10/100 RJ-45
connectors (includes front–panel metal sheet)
6KP3-G2SC “G+2” module, with one GBIC transceiver and two 100Mb 2km FX SC
fiber ports connectors (includes front–panel metal sheet)
GBPM-2OTX Two port Gigabit module provides two GBIC open transceiver ports for
a user-selectable GBIC transceiver module
GBPM-COTX One slot Gigabit 6K module provides one GBIC open transceiver port
for a user-selectable GBIC transceiver module
GBIC-SXSC GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-SX
port with multimode SC fiber connector
GBIC-LXSC10 GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-
LX/LH port with 1310nm single mode SC(10km) fiber connector
GBIC-LXSC25 GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-
LX/LH port with 1310nm single mode SC(25km) fiber connector
GBIC-LXSC40 GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-ZX
port with 1550nm, single mode SC(40km) fiber connector
GBIC-LXSC70 GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-ZX
port with 1550nm, single. mode SC(70km) fiber connector.
GBIC-TP GBIC transceiver module for use in GBPM-xOTX. One 802.3ab
1000BASE-T port with RJ-45 connector
Modules with Gb, not using GBICs
6KP5-1CU4RJ “G+4” module, with one GBIC copper(Auto-negotiating) transceiver
and four 10/100 RJ-45 connectors (includes front–panel metal sheet)
6KP5-1CU4MT “G+4” module, with one GBIC copper(Auto-negotiating) transceiver
and four 100Mb MTRJ Fx-Multi-mode connectors (includes front–panel metal sheet)
6KP3-1CU2FXT “G+2” module, with one GBIC copper(Auto-negotiating) transceiver
and four 100Mb ST Fx-Multi-mode connectors (includes front–panel metal sheet)
6KP2-2GSX two-port in one slot Gigabit 6K module, uses one 6K slot and provides two
Gb Fiber SXSC (1000BASE-SX Multi-mode) ports. (includes front–panel metal sheet).
6KP2-2GCU two-port in one slot Gigabit 6K module, uses one 6K slot and provides two
Gb Copper (1000BASE-RJ45 Auto-negotiating) ports. (includes front–panel metal sheet).
6KM-BLNK Blank cover for one 6K32T & 6K32TRC module slot opening in a
Magnum 6K32T & 6K32TRC chassis
CONSOLE CBL Industry standard serial cable, DB-9 connectors for RS-232 “ null-
modem “ connection (sometimes called an Xmodem cable), used to connect a PC or a
character terminal to the Management port.
CONSOLE USB Console attachment cable, serial to USB, cable with one DB9 for the
managed Switch and a USB interface for the USB connector to a PC.
MNS-6K License(Management software)- Preloaded with the latest firmware, license
costs included with each 6K base unit.
