page | 53
Appendix
Specifications
Supported Formats
Standards
• SD-SDI (SMPTE 259M)
• HD-SDI (SMPTE 292M)
• 3G-SDI (SMPTE 424M)
Resolutions (max.) • 1080p Full HD
• 1920 x 1200 (WUXGA)
• 2K
Reference (sync) • NTSC
• PAL
• Tri-Level
Electrical
Input Video Signal
• 1.2V p-p
Input / Output Impedance • 75 Ω
Output Level • 750 mV - 850 mV (p-p)
Connectors
Inputs
• 16 x BNC, female
Outputs • 16 x BNC, female
Reference In • 1 x BNC, female
Reference Loop Out • 1 x BNC, female
IR Extender • 3.5mm mini-stereo
RS-232 • DB-9, female
IP Control • RJ-45, shielded
Operational
Power Input
• 2 x 100 - 240V AC
Power Consumption • 30W (each power supply)
Operating Temperature • +32 to +104° F (0 to +45° C)
Storage Temperature • -4 to +140° F (-20 to +60° C)
Relative Humidity (non-condensing) • +20 to 90%
Physical
Dimensions (W x H x D)
• 19” x 3.5” x 7”
(482mm x 89mm x 178mm)
Unit Weight • 13.8 lbs (6.26 kg)
