RS-232 / IP Commands
Advanced Operation
r
The
r command routes the specified input to the specified output. Do not precede this
command with the “
#” symbol.
Syntax:
r param1 param2
Parameters:
param1
Output
[1
...
16]
param2
Input
[1
...
16]
Example:
r 1 3
Input 3 is routed to output 1
r 5 0
Input 5 is routed to all Outputs
s
The
s command routes the specified input to all outputs. Do not precede this command
with the “
#” symbol. If param1 = 0, then the matrix will be placed in a 1-to-1 routing state.
In other words, Input 1 is routed to Output 1, Input 2 is routed to Output 2, and so on.
Syntax:
s param1
Parameters:
param1
Input
[1
...
16]
Example:
s 2
All outputs are routed to input 2
s 0
Routed 1-1,2-2...
